PPGI Coil

Product Description

PPGI coil is a popular material that uses hot-dip galvanized steel or electro-galvanized steel (galvanized layer) as the base material and is coated with multiple layers of organic coatings to prevent it from rusting. Used in roof panels, wall panels, furniture, home appliances, auto parts, etc. It maintains the strength of galvanized steel while its organic coating offers a variety of colors and an attractive appearance.

Product Description

More details

PPGI is pre-painted galvanized steel, also known as pre-coated steel, color coated steel etc.
Using Hot Dip Galvanized Steel Coil as the substrate, PPGI is made by first going through surface pretreatment, then the coating of one or more layers of liquid coating by roll coating, and finally baking and cooling. The coatings used including polyester, silicon modified polyester, high-durability, corrosion-resistance and formability.

Hot-dip galvanized PPGI steel

Hot-dip galvanized steel sheets are mainly used as the base material. Due to the protection of zinc layer and organic coating, its service life is longer than that of hot-dip galvanized sheets. Available zinc coating is 275 g/m2.

Electro-galvanized PPGI steel

Electro-galvanized sheet is used as the base material. Since the zinc layer of electro-galvanized sheets is thin, usually 20g/㎡, its corrosion resistance is not as good as that of hot-dip galvanized sheets. This product is therefore not suitable for outdoor walls and roofs. But it has beautiful appearance and excellent processing performance, and is mainly used in home appliances, steel furniture, interior decoration, etc.

Selection of color

We offer a wide range of colors to choose from, below are the common colors, if you like other colors or patterns, please send us the RAL color code.

Advantages of PPGI color coated rolls

Color-coated galvanized coil sheets are available in a variety of colors and patterns to meet different styles and uses. The colorful coating also makes PPGI steel more corrosion-resistant and durable. PPGI steel coil has excellent processing properties. So you can make the coils into different products depending on your needs. Color-coated galvanized steel coils also retain the strength of the steel, making it tough and safe. PPGI coated membranes are lightweight and easy to transport and install. Compared with PPGL steel, the price is more affordable.

Surface treatment
Lamination
This process is to apply a transparent organic film (30-50㎛) on the steel coil at high temperature. It has some unique properties such as fire resistance, fingerprint resistance, excellent durability, stain resistance, etc. Obviously, this treatment method can protect the steel coil well during storage and transportation.
embossed
Embossed PPGI steel coils are designed with different patterns. Popular patterns are stucco, diamond, etc. And it's customizable. Compared with smooth steel coils, it has a vivid 3D effect.

Coating type

In coil steel coatings, resins and pigments play a role in durability. The most commonly used topcoats include polyester, silicon-modified polyester, high-durability polyester and polyvinylidene fluoride.
Polyester PE
Good adhesion, rich colors, broad range in formability and outdoor durability, moderate chemical resistance, low cost.
Silicone modified polyester SMP
The coating film has good hardness, abrasion resistance and heat resistance; as well as good external durability, chalking resistance, gloss retention, average flexibility and medium cost.
High durability polyester HDP
Excellent color retention and UV resistance, excellent outdoor durability and chalking resistance, good paint film adhesion, rich colors, and excellent cost performance.
Polyvinylidene fluoride PVDF
Excellent color retention and UV resistance, excellent outdoor durability and chalking resistance, excellent solvent resistance, good formability, stain resistance, limited colors, high cost.

Application scope

Construction industry: such as roofs, interior and exterior wall panels, balcony panels, suspended ceilings, partition walls, windows, door panels, etc.
Transportation: such as car decorative panels, train or ship decks, containers, etc.
Electrical equipment: Mainly used to make casings for freezers, washing machines, air conditioners, etc. PPGI coils for home appliances are of the best quality and have the highest production requirements.
Furniture: such as wardrobes, lockers, radiators, lampshades, tables, beds, bookcases, shelves, etc.
Other industries: such as roller shutters, billboards, traffic signs, elevators, whiteboards, ETC.

Application:
1. Buildings And Constructions Workshop, Warehouse, Corrugated Roof And Wall, Rainwater, Drainage Pipe, Roller Shutter Door
2. Electrical ApplianceRefrigerator, Washer, Switch Cabinet, Instrument Cabinate, Air Conditioning, Micro-Wave Oven, Bread Maker
3. FurnitureCentral Heating Slice, Lampshade, Book Shelf
4. Carrying TradeExterior Decoration Of Auto And Train, Clapboard, Container,Lsolation Board
5.Others Writing Panel, Garbage Can, Billboard, Timekeeper, Typewriter, Instrument Panel, Weight Sensor, Photographic Equipment.
Products Test:
Our coating mass control technology is amongst the most advanced in the world. The sophisticated coating mass gauge ensure accurate control and consistency of coating mass.
Quality Assurance
is committed to deliver a long lasting, quality product that satisfies its valued clients. To achieve this, our brands are produced and tested in accordance to global standards. They are also subjected to:
ISO quality system testing
Quality inspection during production
Quality assurance of the finished product
Artificial weather testing
Live test sites

Products Display

Packaging and shipping
Standard export shipping packaging (waterproof paper and steel tape packaging), suitable for all kinds of transportation, or packaged according to your needs. Each carton is well supported and reinforced. Use 20-foot containers to load 6 meters and 40-foot containers to load 12 meters. We will take photos of container loading and seal the container. Shipping is fast.

Customer Reviews
We have also established a professional international trade service team with sales networks all over the world. With many advantages, we cooperate with customers in North America, South America, Europe, Southeast Asia, the Middle East and Africa, and have established operations in Peru, the Philippines, Russia, Ukraine, Belarus, Uzbekistan, Pakistan, Indonesia, Malaysia, South Africa, Sri Lanka, Turkey, Vietnam, Laos, More than 30 countries including Brazil, Thailand, the Middle East, the United Arab Emirates, Morocco, Spain, the United States, New Zealand, and Iran. The customers we cooperate with have high praise for our products. At the same time, we also have a high-quality after-sales service system, so you can choose our team with confidence.
